Waveshare 8" DSI LCD — 800×480 Capacitive Touchscreen for Raspberry Pi
Waveshare 8" DSI LCD — 800×480 Capacitive Touchscreen for Raspberry Pi
Free shipping within Sweden from 470 SEK
Under 470 SEK: 65 SEK. Rest of the EU from 229 SEK, depending on weight. Every parcel is tracked.
Need a larger quantity?
Volume pricing for schools and companies
Get a quote with price and lead time for larger quantities.
For schools, companies, clubs and project orders.
Order-to-ship: ordered from our distributor when you place your order and shipped to you from Kalmar, Sweden.
The Waveshare 8" DSI LCD is an 800×480 display with 5-point capacitive touch on a toughened glass panel, driven directly from the Raspberry Pi DSI port. It is powered through pogo pins from the Pi, offers software brightness control and provides two 5 V headers for a cooling fan or other low-power accessories. The rear has a camera cut-out and SMD mounting nuts, so a Pi 5 with Active Cooler and a camera module can sit cleanly behind the screen.
Highlights
- 8" panel, 800×480, toughened glass (6H) capacitive touch, 5 points
- DSI video and I2C touch – HDMI and USB stay free
- Powered via pogo pins from the Pi, two 5 V output headers
- Software brightness and VCOM adjustment
- Raspberry Pi 5, 4B, 3B+/3A+/3B, 2B, B+, A+; CM3/CM4, VisionFive 2, Tinker Board 2
In the box
- 1 × 8" DSI LCD
- FPC cable and 2-pin cable
- Mounting screws
Documentation: Waveshare wiki.
Manufacturer: Waveshare, Shenzhen. Importer: Gadwave, Kalmar, Sweden.
