Waveshare 8" HDMI Touch Display (8DP-CAPLCD) — 1280×800 IPS, 10-Point Touch, USB-C
Waveshare 8" HDMI Touch Display (8DP-CAPLCD) — 1280×800 IPS, 10-Point Touch, USB-C
Free shipping within Sweden from 470 SEK
Under 470 SEK: 65 SEK. Rest of the EU from 229 SEK, depending on weight. Every parcel is tracked.
Need a larger quantity?
Volume pricing for schools and companies
Get a quote with price and lead time for larger quantities.
For schools, companies, clubs and project orders.
Order-to-ship: ordered from our distributor when you place your order and shipped to you from Kalmar, Sweden.
The Waveshare 8DP-CAPLCD is an 8-inch 1280×800 IPS display with 10-point capacitive touch behind an optically bonded toughened glass panel. It takes HDMI video and uses a single USB Type-C port for touch and 5 V power, working driver-free with Raspberry Pi, Jetson Nano and Windows PCs. A separate button board gives an on-screen menu for brightness and contrast, and HDMI audio is available through a 3.5 mm jack or speaker header. The sharpest 8-inch panel in the range – a proper small monitor for a Pi 5 or a Home Assistant wall panel.
Highlights
- 8" IPS panel, 1280×800, 178° viewing angle
- Optically bonded toughened glass (6H), 10-point capacitive touch
- HDMI video; USB-C for touch and 5 V power
- Button board with OSD menu, software brightness control
- 3.5 mm audio jack and 4-pin speaker header
- Driver-free on Raspberry Pi, Jetson Nano (single touch), Windows 11/10/8/7
In the box
- 1 × 8DP-CAPLCD (approx. 406 g)
- HDMI flat cable, HDMI adapters incl. micro-HDMI
- USB-A to USB-C cable and USB-C adapters
- Button board with cable
- Screw and spacer kit
Documentation: Waveshare wiki.
